Deep-Throat Forged Steel Body Clamps

Warning: Wear safety goggles user and bystander

Warning: Tool safety info - Download Safety PDF

Warning: Comfort or plastic grips do not protect against electric shock.

Warning: Wear safety goggles user and bystander

Warning: Tool safety info - Download Safety PDF

Warning: Comfort or plastic grips do not protect against electric shock.

01

features & benefits

Features & benefits

- C-Clamps available in light service, heavy service & extra heavy service with test loads from 3500 lbs.- 40,000 lbs. Both Deep and Extra Deep Throat
- Threads on screws are Acme roll-threaded for maximum strength and clamping force. Light service Clamps have spatter-resisting copper plated screw, swivel and crosspin option for welding applications
- Replacement Screws available for Heavy and Extra-Heavy service Clamps
- Drop Forged Carbon Steel
- Made in the USA
02

products

part number
Country of Origin
Max. OPENING
Min. OPENING
Depth
Screw Diameter
Test Load
Weight Each
Part Number
90402B
Country of Origin
UNITED STATES
Max. OPENING
2"
Min. OPENING
0"
Depth
2"
Screw Diameter
1/2"
Test Load
3,500 lbs.
Weight Each
1-1/2 lbs.
part number 90402B
Part Number
90403B
Country of Origin
UNITED STATES
Max. OPENING
3"
Min. OPENING
0"
Depth
2-3/8"
Screw Diameter
1/2"
Test Load
3,500 lbs.
Weight Each
1-3/4 lbs.
part number 90403B
Part Number
90404B
Country of Origin
UNITED STATES
Max. OPENING
4"
Min. OPENING
0"
Depth
2-3/4"
Screw Diameter
3/4"
Test Load
6,500 lbs.
Weight Each
2-3/4 lbs.
part number 90404B
Part Number
90406B
Country of Origin
UNITED STATES
Max. OPENING
6"
Min. OPENING
0"
Depth
3-5/8"
Screw Diameter
3/4"
Test Load
6,900 lbs.
Weight Each
4-3/4 lbs.
part number 90406B
Part Number
90408B
Country of Origin
UNITED STATES
Max. OPENING
8"
Min. OPENING
0"
Depth
4-1/2"
Screw Diameter
3/4"
Test Load
6,900 lbs.
Weight Each
8-1/2 lbs.
part number 90408B
Part Number
90410B
Country of Origin
UNITED STATES
Max. OPENING
10"
Min. OPENING
0"
Depth
5-3/8"
Screw Diameter
3/4"
Test Load
8,000 lbs.
Weight Each
10-1/2 lbs.
part number 90410B
Part Number
90412B
Country of Origin
UNITED STATES
Max. OPENING
12"
Min. OPENING
0"
Depth
5-3/4"
Screw Diameter
7/8"
Test Load
9,500 lbs.
Weight Each
14 lbs.
part number 90412B
